With Berghaus launching their new Air Flow Pro suspended air back packs

for next spring, 2010, we thought it'd be interesting to run a quick overview of

the different variations on the air-vent

back system theme and their strengths and weaknesses as

well as the pros and cons of ventilated back systems.

vbs01




What's Good Generally?

Mesh back panels hold the main body of the pack away from

your back and allow air to pass over it cooling and venting as it goes.

That means a cooler, less sweaty back and a more efficient physiology

in warm conditions as there's more surface area available to lose heat

from.


What's Not So Good?

The air gap means the load is carried further away from

your back, which in turn can mean you can feel the pack levering away

from your back. To accommodate the back system, pack makers end up with

a long, thin, sometimes curved packing space making them deceptively

low in volume and awkward to pack.

vbs02

Mesh isn't quite as breathable as you might think, a lot of it is still

solid nylon or whatever, so it may not be as cool as you think it

should be. Plus in cold conditions, wind can get at your back making

for a cold, chilled feeling.

Finally, the systems can be weighty thanks to tensioned plates and rods

needed to hold the load away from your back and the mesh.


Overall

To sum up, good in hot conditions but potentially less so

when it's cool and with some inherent weaknesses that need dealing

with, which is what the leading brands have been doing.


Osprey Atmos - Airspeed

The original Atmos was the first ventilated

pack we really got on with. It used mesh tensioned across a flexible

space frame that flexed with your back and shoulder movement and

transferred load brilliantly making for a great carry with no feel of

leverage from the load.

vbs03

The second generation of the Atmos has a modified Airspeed system with

far less flex in it and a LightWire alloy frame backed up by a tightly

tensioned mesh back panel. The frame extends round the hips for better

load transfer and cross struts across the frame hold things stiffer and

control the flex, which gives a shallower air gap which is better for

stability. There's no internal plate, it relies on tension from the

frame which makes it relatively light.

vbs04

The sides aren't completely open, but crescent-shaped holes allow

reasonable side ventilation. Carries well, though the hip area can be

problematic if you're shaped wrongly. Venting not quite as good as some.


Lowe Alpine Air Zone

Centro

Lowe Alpine makes some excellent and innovative packs,

interestingly, they developed a meshless system where two blocks held

the pack off the back giving an uninterrupted air gap. Gregory is doing

something similar for 2010.

vbs07

The company went back to the trampolene model last year though with the

AirZone system. This uses a stiffened plate supported by an internal

alloy frame, which you can't see, but again stiffens the back meaning

Lowe can get away with a smaller air gap thanks to increased stiffness.

The mesh area itself has been minimised  with big cut-outs

allowing air to get straight to the back with no mesh in the way.

Finally an adaptive  hip-belt caters for variations in hip

shape.

vbs08

It's a well developed system that carries very well and still gets as

much air to the back as possible.  Narrow air gap means better

internal space and minimal leverage when loaded up.


New Berghaus FreeFlow Pro

We used the new FreeFlow Pro system at its launch in the

Lakes last week. The standard Freeflow uses flexible glass fibre /

Delrin struts which mean the air gap is easily compressed as the back

plate flexes. To prevent that happening, the new Pro uses a Nylon

backplate reinforced with two strong alloy tubes.

vbs05

This means Berghaus can make the air gap smaller, so in turn, the pack

sits closer to the back for increased stability when loaded up. Like

Lowe Alpine - and Deuter who originated the concept - Berghaus has

removed some of the mesh to reduce contact area with the back. Finally

it too has a hip-belt that adapts to body shape.

vbs06

At the launch we found it carries extremely well and unobtrusively and

there was no leverage even when scrambling. Finally, as promised the

air gap was relatively small, but still effective.


The Alternative - Gregory Packs

At the recent Friedrichshafen OutDoor trade show, Gregory

was showing off its new

back system which, like the discontinued Lowe

Alpine technology. Dubed Jetstream LTS, it uses a curved back plate and

alloy frame, but no mesh. The end result is a full air gap across the

centre of the back.

Gregory201001

We haven't had a chance to use it yet, but bearing in mind the

deceptively limited breathability of mesh panels, it looks like an

interesting development and we're looking forward to trying it out.


Your Choice?

The main brands are getting better and better

at ventilated packs and minising the downsides by reducing air gaps,

increasing air contact with the back and improving load transfer

generally. All the systems we've looked at work far better than earlier

versions.

Our advice would be to try with a loaded pack before buying. The Osprey

system works well, but isn't cheap and has the edge for lightness while

the Lowe Alpine and new Berghaus packs share some similar features.

The Gregory, once it - like the Berghaus - is available in 2010 should

make for an interesting alternative to the mainstream options.
